ORYGEN LUXOR

ORYGEN

ORYGEN - LUXOR

ORYGEN - LORENTZ

Arm System

Double Arm System

Single Arm System

Console Width

1550mm (Standard) & Customizable

Console Specification

200Sq.mm - 2 Nos

Length of the Arms

Main Arm - 1000mm & Extension arm - 850mm

Main Arm - 1000mm

Rotation

Main Arm - 340 Degree , Extension Arm - 340 Degree & Console - 340 Degree

Main Arm - 340 Degree & Console - 340 Degree

Radius Covered

1000mm + 850mm

1000mm

Net Weight of the pendant with accessories

150 KG

100 KG

 Net Load Capacity

100 to 150 Kg

125 to 175 Kg

Bearing Locks

Tapper Roller Bearing - 6 Nos

Tapper Roller Bearing - 4 Nos

Aluminum

Structural profile not less than 10 mm/cover profile not less than 3 - 3.5 mm, Material - Alloy 6063T6

Structural profile not less than 10 mm/cover profile not less than 3 - 3.5 mm, Material -Alloy 6063T6

Pneumatic Braking System (Optional)

Works with Minimum Pressure - 4 Bar to Maximum Pressure - 6 Bar

Medical Gas Outlets

All type of Gas outlets according to National standards (DIN, BS, Med gas, JPN, AGSS & MC70 (Quantity Optional)

Electrical

6 to 16 Amps Switch & Three Pin Socket, RJ45 data connector, telephone connections and etc. (Quantity

Wire minimum section

Electrical sockets 1.5 (or) 2.5 sq.mm Optional)

Accessories

Drawer, Tray, IV Pole, BHU Ward Vacuum unit clamp & SS Basket (Quantity Optional)

Vertical Piping

Seamless steel pipe with 8mm thickness used

Ceiling fixing

Clamped onto the ceiling with (Threaded rod) an adjustable support

Testing

The products are fully tested and ready for immediate installing
